tõsteseekel omega
Kasutus – Raske lasti või kauba tõstmiseks.
Kiire ühendamine ja lahtiühendamine kett-troppidele, trosstroppidele, haaratsitele, konteineritele jne..
Lubatud temperatuur -40°C kuni +204°C
Pinnakate: kuumtsingitud
Toodetel on sertifikaat.
Varutegur 6:1
—
Vajuta pildile, et toodet suuremalt näha..
Andmed:
| Töökoormus | A | B | C | D | E | Kaal |
| 0,5t | 12,5mm | 7,8mm | 28,5mm | 7mm | 19,5mm | 0,05kg |
| 0,75t | 13mm | 9,3mm | 30mm | 8,2mm | 20,5mm | 0,09kg |
| 1t | 17mm | 11mm | 37,5mm | 10mm | 26,5mm | 0,14kg |
| 1,5t | 18mm | 12,5mm | 42,5mm | 10,8mm | 29mm | 0,17kg |
| 2t | 20,5mm | 15,7mm | 49mm | 12,7mm | 32,5mm | 0,33kg |
| 3,25t | 27mm | 18,5mm | 60mm | 16mm | 42,5mm | 0,62kg |
| 4,75t | 32,5mm | 21,5mm | 70,5mm | 19,5mm | 49,5mm | 1,07kg |
| 6,5t | 37,5mm | 24,5mm | 84,5mm | 23mm | 57,5mm | 1,64kg |
| 8,5t | 43mm | 27,5mm | 95mm | 26mm | 68mm | 2,28kg |
| 9,5t | 45mm | 32mm | 106mm | 29mm | 72,5mm | 3,36kg |
| 12t | 49mm | 35mm | 118mm | 33mm | 80mm | 4,31kg |
| 13,5t | 57mm | 37,5mm | 134mm | 35mm | 91mm | 6,14kg |
| 17t | 62mm | 41,5mm | 149mm | 38mm | 98mm | 7,8kg |
| 25t | 75mm | 49,5mm | 176mm | 47,5mm | 126,5mm | 12,6kg |
| 35t | 82,5mm | 57mm | 197mm | 53mm | 146mm | 20,4kg |
| 55t | 105mm | 70mm | 267mm | 69mm | 185mm | 38,9kg |
| 85t | 127mm | 82,5mm | 330mm | 76mm | 200mm | 70kg |
Päringut tehes kirjutage soovitud tõsteseekli töökoormus ja kogus.
